Touch-Display (15 Zoll)
Modelnummer: M337RB
- Schlankes und stilvolles Design
- Resistiver Touchscreen
- Abnehmbarer Standfuß/ für VESA-Halterung geeignet
- Spritzwasserschutz und staubabweisend
- Geeignet für 2. Display und MSR-Leser
- Siehe M437 mit Standfuß
Specification
| M337 | |
| MODEL | |
| M337RB | |
| Description | |
| 15″ VGA/DVI Resistive (4:3) | |
| Display | |
| Display Size | 15″ |
| True-Flat | N/A |
| Interface | VGA+DVI |
| Resolution | 1024 x 768 |
| Viewing Angle | 70/70/80/80 degree (U/D/L/R) |
| Brightness (nits) | 250 |
| Contrast Ratio | 700 : 1 |
| Response Time (ms) | 16 |
| Power Supply | DC 12V |
| OS Support | Windows 10 、 8.1 、 8 、 7 |
| Touch Type | |
| Touch Type | 5-Wire Resistive |
| Input Terminals | |
| For Video Signal | D-Sub 15-pin, DVI-D |
| For Power | DC Jack |
| For Touch Signal | USB Type B or DB9 |
| For VFD | RJ48 |
| For Peripherals | USB Type A *2 |
| For Audio | N/A |
| Physical Dimension | |
| Dimensions (W x H x D) mm |
365.7 x 323.5 x 51 |
| Weight (N. W.) (Kg) | 3.5 |
| Environment | |
| Operating Condition | 0ºC~40ºC |
| Storage Condition | -10ºC~50ºC |
| Power Consumption | Max. 20W |
| Certifications | |
| EMI / Safety | CE, FCC |
| Options | |
| Wall Mount Kit | Option, 75 x 75mm VESA |
| Base | Option |
| MSR | Option |
| VFD | Option |
| Pole Stand | N/A |
| 2nd Display | N/A |
